Trendnet TPE-3524SF

Specifications

TRENDnet 52-Port Gigabit Web Smart 740W PoE+ Switch with 10G SFP+ Slots

TRENDnet’s 52-Port Gigabit Web Smart PoE+ Switch with 10G SFP+ ports, model TPE-3524SF, offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of SMB networks. This managed PoE+ switch with SFP+ ports comes with an intuitive web-based interface. Advanced managed switch features include LACP to group ports together to increase TPE-3524SF bandwidth between switches, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this a powerful solution for SMB networks. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with the easy-to-use voice VLAN feature. Free up router resources by offloading routing processes to the managed switch by using the L2+ Managed IPv4/IPv6 static routing feature to efficiently route traffic at the switch level. The dynamic ARP inspection feature helps protect connected devices from manin-the-middle attacks by discarding malicious and invalid ARP packets. Take advantage of the available multicast and IGMP/MLD snooping features to optimize IP surveillance system performance, and minimize network traffic. This TRENDnet Web Smart Managed PoE+ Switch also feature 10G SFP+ portsports to support long-distance fiber networking applications.

Key Features:

• 48 x Gigabit PoE+ ports
• 4 x 10G SFP+ ports
• 740W PoE power budget
• Easy-to-use web-based management interface
• Supports IPv6, LACP, VLAN, QoS, and IGMP/MLD Snooping
• IPv4/IPv6 Static Routing support
• Bandwidth control per port
• Private, Multicast, and Voice VLAN support
• Smart fan
• 176Gbps switching capacity
• IEEE 802.1p QoS with queue scheduling support
• Lifetime Warranty
• NDAA / TAA compliant (U.S. and Canada only)

Hardware Design

Provides gigabit ports for device connections, 10G SFP+ portsports for fiber applications, and a 1U 19” rackmount design with brackets included

IPv6 Ready

This managed PoE+ switch with SFP+ ports supports IPv6 configuration and IPv6 neighbor discovery

Dynamic ARP Inspection

Dynamic ARP inspection feature helps protect connected devices from man-in-the-middle attacks by discarding malicious and invalid ARP packets

Monitoring

RMON, SNMP, SNMP Trap, and Port Mirroring support administrator monitoring solutions

Jumbo Frame

Sends larger packets, or Jumbo Frames (up to 9KB) for increased performance

PoE Power

A 740W total PoE power budget on the managed PoE+ switch supplies Power over Ethernet devices with up to 30W per port

Traffic Management

Managed switch features include: Link aggregation, 802.1Q VLAN, Voice VLAN, Multicast VLAN, RSTP, MSTP, Loopback Detection, QoS, and port bandwidth management

Troubleshooting

A convenient cable diagnostic test and traffic statistics aid in network troubleshooting

Smart Fan

The smart fan on this managed PoE+ switch with SFP+ ports saves energy by auto-adjusting the fan speed and use based on cooling needs

LED Indicators

LED indicators on this managed PoE+ switch with SFP+ ports convey port status

10G SFP+ Ports

Offers four dedicated 10G SFP+ ports for high-speed network connections, providing a costeffective solution in adding 10G link capability to an SMB network

IPv4/IPv6 Static Routing

Offload routing processes to the managed PoE+ switch by using the L2+ IPv4/IPv6 static routing feature to efficiently route traffic at the switch level

Access Control

Includes ACL, SSL, MAC/port filtering, 802.1X, TACACS+, and RADIUS

Housing Design

Sturdy rack mountable metal housing
