Trendnet TI-BG104
Trendnet - 10-Port Industrial Gigabit PoE++ DIN-Rail Switch, 4 x Gigabit PoE++ ports, 4 x Gigabit PoE+ ports, 2 x Gigabit Share ports (SFP or RJ-45), 20Gbps switching capacity, Hardened IP30 rated metal switch, ncludes DIN-Rail and wall mounts, Extreme operating temperature range of -40° 75° C (-40° 167° F), Dual power inputs for redundancy, Alarm output triggered by power failure, Power supply sold separately (TI-S48048), 360W power budget.
Thumbnail Filmstrip of Trendnet TI-BG104 Images
SKU: TIBG104
Trendnet TI-BG104
Please sign in to purchase.
Specifications
TRENDnet 10-Port Industrial Gigabit PoE++ DIN-Rail Switch
TRENDnet’s 60 W Single Output Industrial DIN-Rail Power Supply, model TI-M6024 (Mean Well MDR-60-24), supplies up to 60 Watts of power to industrial PoE equipment such as switches, network cameras, and WiFi access points. This power supply comes with an integrated DIN-rail mount and overload current protection.
Key Features:
- 4 x Gigabit PoE++ ports
- 4 x Gigabit PoE+ ports
- 2 x Gigabit Share ports (SFP or RJ-45)
- 360W power budget
- 20Gbps switching capacity
- Hardened IP30 rated metal switch
- Includes DIN-Rail and wall mounts
- Extreme operating temperature range of -40° – 75° C (-40° – 167° F)
- Dual power inputs for redundancy
- Alarm output triggered by power failure
- Power supply sold separately (TI-S48048)
PoE Power Budget
A 360W PoE power budget on this industrial 802.3bt PoE++ switch supports up to eight Power over Ethernet devices with PoE (15.4W), PoE+ (30W), or PoE++ (90W) power
Network Ports
4 x Gigabit PoE++ ports (802.3bt PoE++ ports), 4 x Gigabit PoE+ ports, and 2 x Gigabit share ports (SFP or RJ-45)
DIN-Rail/Wall Mounts
IP30 rated metal enclosure with included DIN-Rail and wall mount hardware
Switching Capacity
20Gbps switching capacity
Redundant Power
Dual power inputs for redundancy with overload current protection (power supplies sold separately, model TIS48048)
Alarm Relay
Industrial PoE++ switch’s alarm relay is triggered by power failure of primary and/or redundant power
Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 10KB), for increased performance
Rated for Extreme Environments
Rugged IP30 rated enclosure designed to withstand a high degree of vibration and shock, and operate within a wide temperature range (- 40°– 75° C (- 40° - 167° F)) for harsh environments
Shock and Vibration Resistant
Rated for shock (IEC 60068-2-27), freefall (IEC 60068-2-32), and vibration (IEC 60068-2-6)
Grounding Point
Grounding point on the industrial PoE++ switch protects equipment against external electrical surges
